• Grade:

    C17200, C17500, C17510

    W.-Nr 2.1247, 2.1258, 2.085

    CW101C, CW104C, CW110C

    CuBe2, CuBe1.9, CuCo2Be, CuNi2Be

    Copper-beryllium, Copper-cobalt-beryllium, Copper-nicke-beryllium

 • Thickness: 0.05 – 6.00 mm

 • Length: up to 300mm

 • Weight per coil: max.100kgs

 • Temper:

    A (TB00),½ H (TD02), H(TD04), AT(TF00),  ½ H (TH02), HT(TH04)

    or customize as client's requirements

• Standard:

   ASTM B 194, ASTM B 534, AMS 4530, AMS 4532

 • Excellent strength

 • Excellent endurance

 • Isotropic

 • Forming characteristics

 • Nondirectional properties

 • High fatigue strength

 • High hardness

 • Shielding strips

 • Relay contacts and switch parts

 • Disc diaphragms

 • Formed spring

 • Connector
